VC-7P STUDIO (pair)

$899.99

Meticulously designed and hand-built by Von Hertzog at The Social Club, the VC-7 STUDIO features a low distortion 7 inch aluminum woofer and a Norwegian-built  27mm SEAS Aluminum/Magnesium tweeter. With a nominal impedance of 8 ohms, the port in the enclosure is tuned low enough to produce an in-room F6 of 46Hz.

Available on backorder

Qty:
Compare

Meticulously designed and hand-built by Von Hertzog at The Social Club, the VC-7 STUDIO features a low distortion 7 inch aluminum woofer and a Norwegian-built  27mm SEAS Aluminum/Magnesium tweeter. With a nominal impedance of 8 ohms, the port in the enclosure is tuned low enough to produce an in-room F6 of 46Hz.

7″ Aluminum Cone Woofer Highlights

  • Special composite dustcap
  • Rubber surround
  • Flat spider
  • Stamped steel frame
  • Aluminum cone offers a flat frequency response in the passband region with very low distortion

SEAS Prestige 27mm Tweeter Highlights

  • High Definition metal dome tweeter with a wide, soft polymer surround and a rear chamber.
  • Aluminium/magnesium alloy diaphragm with pistonic behavior throughout the audible frequency range, resulting in a good dispersion also above 10kHz.
  • A Hexagrid protects the diaphragm, and supports a phase plate which compensates for a slight axial roll off towards 20 kHz.
  • Sonomax surround for low resonance and excellent mechanical linearity
  • Voice coil windings immersed in magnetic fluid increase short term power handling capacity and reduce the compression at high power levels.
  • Stiff and stable rear chamber with optimal acoustic damping allows the tweeter to be used with moderately low crossover frequencies.
  • Precision moulded chassis from glass fibre reinforced plastic, and its front design offers optimum radiation conditions.

Crossover Highlights

  • All Jantzen 18AWG Air Core Inductors
  • Solen (France) & Audyn (Germany) Capacitors
  • Designed for super-low microphonics
  • All Mundorf Metal-Oxide Resistors
  • Point-to-point connection soldered

Specifications

Enclosure Type

Ported

Crossover Type

Two-way

Drivers

1″ aluminum/magnesium tweeter
7” aluminum cone woofer

Crossover point

1500 Hz

Impedance

8 Ω

Sensitivity

82dB

Power recommendation

25 – 150 W

Measurements

8.5″ x 15″ x 12″

Weight

12 lbs (each)

Handmade in the USA
